Rubber Tile Making Machine – High Efficiency Hydraulic Press for Rubber Floor Tiles

Main uses and application areas

Recycling of waste tires: Processing tire particles into rubber floor tiles to promote environmental protection

Gyms and sports venues: producing high-intensity sports mats, anti slip and shock-absorbing

Livestock breeding industry: producing antibacterial and anti slip floor tiles that are easy to clean

Municipal public facilities: production of permeable bricks for park trails and anti fatigue floor mats

Industrial plant: producing oil resistant and corrosion-resistant industrial floor mats

Product highlights and technological advantages

• PLC fully automatic control: using Siemens/Mitsubishi PLC control system, one click operation, can store multiple formulas

• Automatic exhaust and pressure compensation: can effectively eliminate gas in the rubber material and prevent the production of bubbles in the product; Automatic pressure compensation for pressure drop

• Manual/electric push-pull mold system: supports manual or automatic push-pull, significantly reducing labor intensity

• Large workbench: standard countertops of 550 × 550mm and 1200 × 1200mm, supporting large-scale production

• Flexible mold opening+stable guidance: four column/frame structure ensures the accuracy of mold centering

• High quality temperature control: The temperature deviation of the hot plate can be controlled within ± 1 ℃ to ensure uniform vulcanization

• Non standard customization: Tonnage, heating method, and hot plate size can be customized according to demand

• Optional configuration and customized services

• Heating methods: electric heating (standard), thermal oil heating, steam heating

• Electrical configuration: Brands such as Chint, Siemens, Mitsubishi, etc

• Push pull mode: manual push pull, automatic push pull/hydraulic push out

• Temperature control accuracy: ordinary ± 2 ℃/high-precision ± 1 ℃

• Safety devices: safety light curtain, protective cover, emergency stop switch

• Mold support: can be customized according to the drawings or samples provided by the user

Production process (complete process from raw materials to finished products)

Step 1- Mixing: Mix the rubber particles and polyurethane adhesive in proportion in a mixing drum

Step 2- Weighing: Weigh the required weight according to the thickness of the floor tiles

Step 3- Laying: Spread the mixture evenly in the mold, first lay the colored surface layer, and then lay the black bottom layer

Step 4- Sulfurization molding: Push the mold into the vulcanizing machine, set the vulcanization time according to the thickness, and automatically exhaust

Step 5- Demoulding Cooling: The mold automatically exits, and the finished product is taken out and placed on a drying rack for natural cooling

New Parkson Rubber Machinery specializes in producing rubber floor tile vulcanizing machines, which support electric heating/oil heating, PLC control, automatic exhaust, and automatic pressure compensation. They are used for producing waste tire floor tiles, gym sports mats, animal husbandry floors, etc. Support non-standard customization, welcome to inquire.
